Simple and modern – VanEssa´s surfer bed in you campervan

This sleeping system is build up of only two parts and installed faster then any other bed.

With our surfer bed, you are always flexible for variable seating combinations while driving:

• no back seats
• one or two single seats
• Multivan / Beach: folded triple-bench
• Transporter / Caravelle - short wheelbase: the front row of seats can remain in the vehicle, two-seater bench seat only in conjunction with aluminium folding support (see variants / selection by dropdown)
• Transporter / Caravelle - long wheelbase: the front row of seats can remain in the vehicle, two-seater bench only in conjunction with bed shortening (see variants / selection by dropdown)

During the journey, the system rests in the luggage compartment. The passenger compartment and all available seats can be fully used
Your van remains an everyday vehicle that can be converted into a motorhome as required.

Overview and advantages​

• comfortable bed area as a double bed
• high-quality, comfortable VanEssa COMFORT sleeping surface
• lots of storage space
• load-through option for bulky items
• very easy to assemble and disassemble
• optimal subdivision in the boot due to the deep rear board
• Sleeping board and mattress can be stored on the rear board while driving to save space

That leaves you flexible. Different everyday situations are no problem anymore. While driving, our system stays in the back of your car, all seats can be used.

This system is to be connected with our rear kitchen.


Assembly

• Fix the rear kitchen to the original rail system in the boot.
• Hang the kitchen extension (extension board) on the rear kitchen and stabilise it on aluminium supports.
• Push the sleeping board forward and place the folding support vertically in the front passenger compartment.
• Spread out the sleeping surface, ready!



Variants

Mandatory selection via dropdown:

Transporter/Caravelle
short wheelbase

• with separate aluminium folding support: two-seater bench (with or without single seat) should be able to remain installed in the vehicle
• none: Two-bench/single seat are removed

long wheelbase

• with bed shortened to 184 cm: two-seater bench (with or without single seat) should be able to be used with the bed removed
• none: Two-seater bench/single seat are removed or can be folded under the bed and used as a bed support.

California Beach

• with bed shortening to 184 cm: if a VanEssa interior module is installed behind the driver's seat or is to be installed in future
• None: if a VanEssa interior module is never installed behind the driver's seat.

Please send us a picture of the opened boot of your van via picture upload (or by Email) to see the attachment points, seats etc. of your vehicle.
Also do so if you are unsure of the configuration.

Details

Material
poplar plywood with CPL-coating in silver-grey (mini-pearl surface)

  VanEssa care and cleaning instructions "furniture"
  VanEssa product and care info "mattress"

Total bed area / mattress size
COMFORT Mattress,3 pcs, approx. width 143 cm (tapered to 135 cm at the rear), length 189 cm, height 10 cm

packing dimensions (expanded)
Sleeping System (without mattress) approx. width 137 cm, length 94 cm, height 6 cm
Mattress approx. width 143 cm, length 63 cm, height 30 cm

Weight: 29 kg (17 kg +mattress 12 kg)

Load capacity approx. 250 kg

Scope of supply

• Kitchen extension to the rear kitchen with two aluminium supports
• 1 sleeping board with supporting board
• one 3-part mattress: width 143 cm, length 189 cm, height 10 cm (Comfort)
• all mounting parts included in delivery
